Unique Human Voice Alarm system

The device triggered the human voice prompt and stop injection automatically when there is any malfunction, making the infusion process safer and more reliable.

Rate:

50/60ml Syringe:  0.1ml/h～999.9ml/h   (0.1ml/h step)
1,000ml/h～1,500ml/h   (1ml/h  step)
30ml Syringe:  0.1ml/h～900.0ml/h    (0.1ml/h step)
20ml Syringe:  0.1ml/h～600.0ml/h   (0.1ml/h step)
10ml Syringe:  0.1ml/h～300.0ml/h   (0.1ml/h step)

Flow Rate Accuracy:

Within ±3% (after correct calibration)

Mechanical precision:

Within ±2%

Bolus Rate:

50/60ml Syringe:  1,200ml/h
30 ml Syringe:  720ml/h
20 ml Syringe:  480ml/h
10 ml Syringe:  240ml/h

Purge Rate:

50/60ml Syringe:  1,500ml/h
30ml Syringe:  900ml/h
20ml Syringe:  600ml/h
10ml Syringe:  300ml/h

Volume Limit:

0.1ml～999.9ml

Total Injection
Volume:

0.1ml～9999.9ml (0.1ml step)

Occlusion:

High:   800mmHg ±200mmHg     (106.7kPa±26.7kPa
Medium: 50/600mmHg ±100mmHg  (66.7kPa±13.3kPa
Low:    300mmHg ±100mmHg    (40.7kPa±13.3kPa )

Alarms:

Injection soon finish, end of injection,occlusion, improperly installation of syringe, wrong setting, low battery, syringe loose etc.

Power Source:

AC 100V～240V, 50/60Hz; Internal rechargeable Li battery, capacity≥1,600mAh, 4 hours internal battery backup

KVO rate:

1ml/h

Fuse:

F1AL/250/60V, 2pcs inside

Power Consumption:

30VA

IP Classification:

IPX1

Equipment Classification:

Class I, internal power supply, Type CF

Operating Condition:

Ambient temperature: +5℃～+40℃;

Relative humidity:

20～90%

Transport & Storage Condition:

Ambient temperature: -30℃～+55℃

Relative humidity:

≤95%

Dimension:

280mm (L) × 210mm (W) × 130mm (H)

Weight:

2.2kg (net weight)
